Products > Ground engaging tools (G.E.T.)
PRODUCTS
Ground engaging tools (G.E.T.)
| Proudcts ranges | Bucket tooth, adapter, side cutter, ripper tip, protector, heel shroud, baldes, cutting edges, tooth pin and lock, bolt and nut, etc. |
| Application Machines | Caterpillar®, Komatsu®, JCB®, Hitachi®, Kobelco®, Daewoo®, Hyundai®, VOLVO, as well as other earthmoing machinery D3C D4D D6 D20 D20-1 D20-2 D30 D31-15 D31-16 D31-17 D31-18 D31P-21 D41P-6K D41E-6K D41P-6 |
Our G.E.T. achieves the best combination of the impact and abrasion resistance by carefully selection of the right materials and property heat treatment process.
| G.E.T. | 机械性能Mechanical Propery | 适用环境Working Condition | |||
| Tensile抗拉 | Enlongation延展 | Impact(AKV)冲击 | HRC硬度 | ||
| T1 | ≥1400 | ≥2 | 17-20J | 48-55 | 普通作业环境Normal Condition |
| T2 | ≥1600 | ≥3 | 20℃≥20J | 48-55 | 较复杂的砂土石等环境Bad Condition |
| -40℃≥12J | |||||
| T3 | ≥1600 | ≥3 | 20℃≥20J | 48-55 | 严寒、恶劣的作业环境Chilly, harsh, cold,mining Condition |
| -40℃≥17J | |||||
